Overview
Quick Details
- Place of Origin:
- Guangdong, China
- Brand Name:
- Vmaxpower
- Application:
- Solar power stations, off-grid systems, home photovoltaic systems
- Rated Power：
- 1000W
- Certificate:
- CE,ISO 9001,ISO 14001
- Warranty:
- 2 Years
- Output waveform:
- Pure Sine Wave
- Battery Capacity:
- 100AH
- Frequency:
- 50/60Hz
- Display:
- Digital display
- Colour:
- Blue/Black/White
- Environmental Temperature:
- -0+55C
| Model | 300W | 500W | 600W | 1000W | 1500W | 2000W | |
| Rated Power | 300W | 500W | 600W | 1000W | 1500W | 2000W | |
| 3.7V Electricity WH | 296 | 592 | 740 | 1480 | 1480 | 2960 | |
| 3.2V Electricity WH | 256 | 512 | 640 | 1280 | 1280 | 2560 | |
| Lithium Battery Capacity | 20AH | 40AH | 50AH | 100AH | 100AH | 200AH | |
| Photovoltaic Adapter | All Series Optional Photovoltaic Charging | ||||||
| Photovoltaic Panel Power Rate | 100W | 100W | 200W | 200W | 200W | 200W | |
| High Efficient Controller | 12V20A | 12V40A | 12V50A | 12V60A | 12V60A | 12V60A | |
| PV Input Range | 16-50V | 16-50V | 16-50V | 16-50V | 30-50V | 30-50V | |
| Lithium Battery Capacity | 20AH | 40AH | 50AH | 100AH | 100AH | 200AH | |
| Input | Voltage | AC165-275V/ AC85-135V | |||||
| Frequency | 50Hz/60Hz | ||||||
| Output | Voltage | 220/230/240V/110/115/120V | |||||
| Frequency | 50HZ-60HZ Factory Preset | ||||||
| Wave | Pure Sine Wave | ||||||
| Distortion | <3% | ||||||
| Effectiveness | >85% | ||||||
| Battery | Types | Optional | |||||
| Rated Voltage | DC12V | ||||||
| Charging Current | 0-30A Optional | ||||||
| Protection | Over Temperature, Overload, Short Circuit, The Low Voltage of Battery, The High Voltage of Battery, AC Input High Voltage/Low Voltage Protection | ||||||
| Way of Working | Normal, Energy Saving Factory Preset | ||||||
| Conversion Time | <10ms | ||||||
| Load Capacity | 100%-120% 30 Seconds Protection，125%-140% 15 Seconds Protection，>150% 5 Seconds Protection | ||||||
| Working Environment | Temperature | 0-50 Degree | |||||
| Humidity | 10%-90% Does Not Condense | ||||||
| Electrical Consumption Equipment（Power-rate Reference） | 300w | 500w | 600w | 1000w | 1500w | 2000w | Time/Frequency |
| The Battery Capacity of Photovoltaic Mobile Power | 20AH | 40AH | 50AH | 100AH | 100AH | 200AH | |
| Cellphone （4500hAm） | 9 | 18 | 20 | 38 | 54 | 75 | Frequency |
| Kettle（800w） | --- | --- | --- | 1 | 1.5 | 2 | Hour |
| Laptop（60w） | 5 | 8 | 12 | 16 | 25 | 32 | Hour |
| Induction Cooker（1300w） | --- | --- | --- | 0.6 | 1 | 1.5 | Hour |
| Electric Drill（800w） | --- | --- | --- | 1.2 | 1.8 | 2.5 | Hour |
| Car Refrigerator（60w） | 5 | 8 | 10 | 16 | 25 | 32 | Hour |
| Rice Cooker（500w） | --- | --- | 1~3 | 2~4 | 3~6 | 4~8 | Frequency |
Package & Shipping
Batteries have high requirements for transportation.
For questions about sea transportation, air transportation and road transportation, please consult us.
Multifit Office-Our Company
HQ located in Beijing, China and founded in 2009 Our factory located in 3/F,JieSi Bldg.,6 Keji West Road,Hi-Tech Zone,Shantou,Guangdong,China.
Multifit was founded in 2009...
Guess what you want to know
Company Qualification
This solar energy mobile power supply is suitable for people who need power at any time such as travel, exploration, maintenance equipment and so on. It can be charged at any time to meet user's demand for electricity, so that it does not need to delay the process of work because of the lack of the power.I am satisfacted with this mobile power station. It is not only convinient but also movable.I don't need to worry about the electricity when i am traveling. Good buyer who can be trusted.
1. Please try to keep the storage temperature of the product between 0 ° C and 50 ° C. 2. If the product is used in an overheated or overcooled environment, it may be temporarily unable to operate even if the product itself has power surplus. 3. Do not throw the product into the fire, as it may explode. 4. Please do not touch the product with liquid or make it is subjected to strong impact. 5. Do not fall, beat, disassemble the equipment or repair it by yourself. 6. Dispose of discarded electronic products in accordance with local laws and regulations.♦Pure sine wave output ♦Equip with diverse USB ports ♦Smart system, Circuit protection ♦Mains / Photovoltaic Charging / Car Cigarette Lighter Charging(Optional) ♦This whole series comes with the dual-port universal socket ♦Car cigarette lighter, Emergency lighting ♦High Power Rate, can solve various electricity demands
High efficiency, stability and no damage
Ideal current pure sine wave,the output waveform is the same as the mains,Stable and no damage to charging equipment.
